Specific Applications

·Hydraulic power units (HPUs)
·Injection molding machines
·Hydraulic presses
·Machine tools
·Construction machinery
·Industrial automation systems
·Hydraulic manifold systems
·Manufacturing equipment

Core Functions

Solenoid-Actuated Pressure Control
The Subplate Solenoid Relief Valve uses an electrical solenoid to control pressure relief or unloading functions, enabling convenient remote operation and improved hydraulic system automation.

Reliable Overpressure Protection
The valve automatically relieves pressure when system pressure reaches the preset value, helping protect pumps, cylinders, valves, and other hydraulic components.

High Pressure and Flow Capacity
Based on Model DBW-10, the Subplate Solenoid Relief Valve supports a maximum operating pressure of 315 bar and a maximum flow rate of 250 L/min (66.05 gpm), making it suitable for medium- and high-flow hydraulic circuits.

Standard Subplate Installation
The subplate mounting design simplifies installation, replacement, and maintenance while ensuring compatibility with standardized hydraulic systems.

Stable Hydraulic Performance
The valve combines reliable solenoid operation with stable pressure regulation, helping maintain consistent hydraulic system performance during continuous operation.

Technical Specifications
Model Number Maximum Pressure(bar) Minimum adjustment pressure Maximum Flow Rate
(Ipm)
Weight
(kg)
DBV-10 315(4500 psi) Please refer to the minimum adjustment pressure characteristics. 250(66.05gpm) 5.2
DBV-20 500(132.09gpm) 6.5
DBW-30 650(171.72gpm) 8.5

ttosiydo1787130369

mymlsrwc1787130374


OEM / ODM Customization

We provide OEM and ODM services for hydraulic solenoid relief valves to meet different application requirements.

·Pressure setting customization
·Solenoid voltage customization
·Subplate interface customization
·Port configuration customization
·Seal material selection
·Logo marking and packaging customization
·Hydraulic system integration support

Purchasing Information

Item

Details

MOQ

Standard cartridge valves: 100 pcs/model; Custom manifold blocks: 30 pcs minimum. Small trial orders are accepted.

Lead Time

Stock valves: 2 weeks; Regular orders: 6–8 weeks; Custom products: about 8 weeks after drawing approval and deposit.

Payment Terms

30% T/T deposit, 70% balance before shipment. Sample orders require full payment. L/C is negotiable for long-term customers.

Trade Terms

FOB Ningbo by default. CIF quotations are available upon request.

Sample Policy

Stock samples are available. OEM/ODM samples can be produced based on drawings or samples.

OEM / ODM

Logo engraving, customized packaging, and product customization are supported.

Quality Assurance

Every valve is pressure-tested before shipment and covered by a 12-month warranty.

FAQ

1. What is a subplate solenoid relief valve used for?
A subplate solenoid relief valve is used to provide electrical pressure control, remote unloading, and overpressure protection in hydraulic systems.

2. What models are available for this series?
Representative models include DBW-10, DBW-20, and DBW-30, suitable for different hydraulic system capacities.

3. What are the pressure and flow capabilities of this valve?
Based on Model DBW-10, the valve provides a maximum operating pressure of 315 bar and a maximum flow rate of 250 L/min (66.05 gpm).

4. What are the advantages of solenoid actuation?
Solenoid actuation enables remote electrical control, faster system response, easier integration with automation equipment, and convenient hydraulic pressure management.

5. How can I choose the right Subplate Solenoid Relief Valve model?
Selection should be based on operating pressure, flow capacity, solenoid voltage, mounting standard, and hydraulic circuit requirements. The appropriate Subplate Solenoid Relief Valve model should be selected according to the actual application conditions.
